802BT/802R Video Test Generator User Guide

If your monitor is used in word processor workstations or other applications that call for

large amounts of text to be displayed, you can use this image to simulate actual user

Select a suitable font size and text color. Adjust your monitor's brightness and contrast

controls to obtain the best image. The characters in all areas of the display should be well

formed and in focus.

Special test image developed per customer specifications. There are two sub images, the

secondary image is depicted below. The top half of the image has three small boxes (red,

green, blue) with the upper left half at 92.7% luminence and the upper right half at 50%
