90 Chapter 6 Working with Test Sequences
deactivate the mode status of all other sequence files. If a start-up mode is not set for
any sequence file, then the generator will start in the normal operating mode.
Mode Display option
blank
step
step -s#
step -display
wrap
wrap -s#
wrap -display
auto
auto -s#
auto -display
9. Press Save (DCS) to save the sequence file. Use the Format and Image knobs to
specify a name for the file by selecting the characters presented.
10. Press Exit (Image) to exit the Sequence Editor, and to return to the Sequence List
editor.
To edit the list of sequences that can be used:
1. Hold down the Image key while starting the generator, until programmer is displayed.
2. Select the SeqList image.
3. Press the Image key to start the Sequence List editor.
The Sequence List box shows a list of sequence files that can be selected with the
Format knob. The Available Files box shows all sequence files available.
Description
If no mode is specified the sequence is not started when the
generator is started.
Use the Image knob to advance through sequence steps.
You cannot advance past the last step. However, rotating the
Image knob forward one revolution past the last step will
change the mode to automatic. Rotating the Image knob
backward one revolution changes the mode back to manual.
Step information is displayed on the LCD only.
Current step number is displayed with image on display
being tested.
Complete step information (sequence name, format, image,
and step number) is displayed with image on display being
tested.
Use Image knob to advance through sequence steps.
Advancing past the last step restarts at the first step.
Step information is displayed on the LCD only.
Current step number is displayed with image on display
being tested.
Complete step information is displayed with image on dis-
play being tested.
Automatically and continuously cycles though sequence
steps, and displays step information on LCD only.
Current step number is displayed with image on display
being tested.
Complete step information is displayed with image on dis-
play being tested.
