Measuring basic timing parameters

802BT/802R Video Test Generator User Guide
• To select a number for a digit, turn the Image knob.
As the number in the Format field changes, the appropriate timing parameters for the
selection appear in the box under the Format Parameters field.
5. If using an HDMI/DVI signal originating externally from the generator, follow these
steps:
a. Select MEASURED in the highlighted field.
b. Select the Format Parameters field using the Format knob.
c. Capture the external signal's timing parameters by pressing and releasing the B
key.
d. Configure the HDMI/DVI transmit device to output an HDMI/DVI signal.
After a few seconds, the external signal's timing parameters are displayed in the box
under Format Parameters and in the Run Length(Hex) field.
Important: If the external source signal's timing parameters change (or the field
selection is changed), the signal timing parameters must be recaptured.
6. Press and release the Step key to save the currently displayed parameters.
The light on the Step key extinguishes, and the new settings are implemented for
analyzer mode operation.
To view basic timing information of an external HDMI/DVI source signal:
1. Connect the HDMI/DVI transmit device to the HDMI/DVI Rx connector on the generator.
2. If necessary, set the proper HDMI/DVI signal source parameters within the generator.
• See "Starting the Analyzer Setup
current analyzer configuration.
• To edit HDMI/DVI signal source parameters, see
timing" on page 114.
3. If desired, monitor the video signal received on the HDMI Rx connector (see page 110).
4. Start the analyzer (see
5. Press and release the R key to display the horizontal and vertical frequencies of the
HDMI/DVI signal on the LCD (see example below).
HS rate VS rate
48076 72.188
Utility" on page 112 for steps on viewing the
"Starting the analyzer" on page 113).
"Setting up analyzer to measure
115
