Summary of special modes

802BT/802R Video Test Generator User Guide
The following table describes the special operating modes, and how to configure the
modes using the physical controls or the command line interface.
Special mode Function
Initialize with factory Re-initializes generator to fac-
defaults tory defaults. Removes all spe-
cial modes, deletes all custom
objects.
Calibrate Calibrates the generator.
Clone Copies configuration settings
from one generator to other
generators using a PCMCIA
card.
Old format library Displays old format names on
LCD.
Remove all modes Removes all special modes.
Set GPIB address Sets the GPIB address.
Set baud rate to 9600 Sets baud rate of RS-232 port
to 9600 bps.
Enable programmable
keypad
Enable numeric key- Enables remote operation
pad through remote keypad.
Analog friendly mode Causes all digital formats to
output analog video signal.
Enable status display Provides additional information
on LCD (analog/digital and
color depth).
DCS priority scheme Changes priority scheme for
putting CS on separate VS and
HS sync outputs when any dig-
ital composite sync (DCS) type
is selected
Digital friendly mode Causes all analog formats out-
put digital signal
Color difference Outputs digital YCbCr for tele-
friendly vision formats.
Reset HDCP Rx gating Resets the receiver, and gates
clock off transmitter clock and data.
Physical control Command
ACS, DSS INIT
R, G, B SCAL
SROP 32
Step, Outputs Set: SROP 64
Rst: SROP
G Set: SROP 1
Rst: SROP
ACS, DCS, DSS Set: SROP 0
DCS Set: GPIB
Rst: INIT
R, DCS Set: SROP 256
Rst: SROP
R, OUTPUT Set: SROP 512
Rst: SROP
R Set: SROP 128
Rst: SROP
R, B Set: SROP 4
Rst: SROP
Step, G, B Set: SROP 8
Rst: SROP
Step, DCS Set: SROP 4096
Rst: SROP
G, B Set: SROP 2
Rst: SROP
B Set: SROP 2048
Rst: SROP
Outputs Set: SROP 16
Rst: SROP
0 64
0 1
addr
0 256
0 512
0 128
0 4
0 8
0 4096
0 2
0 2048
0 16
19
