Standard image descriptions

Acer1
Description
Acer2
Description
604

Appendix B Image Reference

Special test image developed per customer specifications. Consists of two sets of color
bars and five blocks of "#" characters on a white crosshatch with a black background.
Special test image developed per customer specifications. Consists of colorbars, lines of
"#" characters, and a green border.
