Quantum Data 802BT User Manual page 584

XAUD
Class
Description
Command syntax
(individual
parameter)
Command syntax
(complete packet)
574 Appendix A Command Reference
Audio InfoFrame Data
InfoFrame Generator (IFG) parameter
Writes Audio InfoFrame packet data.
XAUD:audparameter value
For uncompressed audio coding type:
XAUD type version length [CC [1 [SS [SF [CA [LSV [DMI ]]]]]]]
For compressed audio coding types:
XAUD type version length [CC [CT [SS [SF [MBR [CA [LSV [DMI ]]]]]]]]
type
4
version
1
length (bytes)
10
The remaining are Audio Infoframe data parameters (audparameter) as specified in
EIA/CEA-861-B standard, Section 6.3:
VERS (same as Version)
Infoframe version
CC
Channel count (see EIA/CEA-861-B standard, Table 19 for settings)
CC2 CC1 CC0 Audio channel count
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Refer to Stream
Header
2ch
3ch
4ch
5ch
6ch
7ch
8ch
