LVDS interface

The LVDS connector is located on the front of the generator and is labeled "Digital." It
emulates a digital host video source and is used for testing LVDS-compliant video
displays. The LVDS connector pinouts are shown in the following table.
Pin Signal Pin
1 A0M 10
2 A1M 11
3 A2M 12
4 Clock 1M 13
5 A3M 14
6 Shield 15
7 No Connection 16
8 No Connection 17
9 No Connection 18
HDMI interface
The HDMI connector is located on the front of the generator and is labeled "HDMI." It
emulates an HDMI-compliant video display. The HDMI connector pinouts are shown in the
following table.
HDMI Type A Connector Pinouts (HDMI option only)
Signal
TMDS Data 2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data1+
TMDS Data1 Shield
TMDS Data1-

Special Sync (S/S) interface

Use the S/S connector to output frame sync, line sync, composite sync, or a special probe
pulse. For more information, see Chapter 12,

S-Video interface

If you have chosen the TV option your generator will have an S-Video connector on the
right side labeled "SVIDEO." This is a miniDIN connector that emulates an S-Video
compliant source for outputting composite TV signal.
Signal Pin Signal
DDC Clock 19 A0P
DDC +5 Vdc 20 A1P
USB+ 21 A2P
USB +5 Vdc 22 Clock 1P
A4M 23 A3P
A5M 24 No Connection
A6M 25 No Connection
A7M 26 No Connection
Clock 2M 27 DDC Ground
Pin Signal
7 TMDS Data0+
8 TMDS Data0 Shield
9 TMDS Data0-
10 TMDS Clock+
11 TMDS Clock Shield
12 TMDS Clock-
"Using Special Sync
Pin Signal
28 DDC Data
29 USB Ground
30 USB-
31 Shield Ground
32 A4P
33 A5P
34 A6P
35 A7P
36 Clock 2P
Pin Signal
13 CEC
14 Reserved (N.C.)
15 SCL
16 SDA
17 DDC/SEC Ground
18 +5 V Power
Output."
