Testing HDMI video

802BT/802R Video Test Generator User Guide
This section provides steps on how to test handling of HDMI video signals by an HDMI
display. To support HDMI, the generator provides pre-defined formats for every video
format specified in the EIA/CEA-861-B standard. These pre-defined formats support all
aspects of the HDMI signal (video, audio, and auxiliary data).
The following table lists the generator formats used to test support for HDMI
(EIA/CEA-861-B) formats.
EIA/CEA-861-B Video
Identification Code
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Quantum Data format
DMT0659, DMT0660
480p59, 480p60, 480p59LH, 480p60LH
480p59SH, 480p60SH
720p59, 720p60
1080i29, 1080i30
480i2x29, 480i2x30, 480i2xL1, 480i2xL2
480i2xS1, 480i2xS2
240p2x_1, 240p2x_2, 240p2x_3, 240p2x_4,
240p2xL1, 240p2xL2, 240p2xL3, 240p2xL4
240p2xS1, 240p2xS4, 240p2xS3, 240p2xS4
480i4x29, 480i4x30, 480i4xL1, 480i4xL2
480i4xS1, 480i4xS2
240p4x_1, 240p4x_2, 240p4x_3, 240p4x_4,
240p4xL1, 240p4xL2, 240p4xL3, 240p4xL4
240p4xS1, 240p4xS2, 240p4xS3, 240p4xS4
480p2x59, 480p2x60, 480p2xL1, 480p2xL2
480p2xS1, 480p2xS2
1080p59, 1080p60
576p50, 576p50LH
576p50SH
720p50
1080i25
576i2x25, 576i2xLH
576i2xSH
288p2x_1, 288p2x_2, 288p2x_3, 288p2xL1,
288p2xL2, 288p2xL3
