Testing HDMI video formats

150 Chapter 9 Testing HDMI Sink Devices
EIA/CEA-861-B Video
Identification Code
24
25
26
27
28
29
30
31
32
33
34
Basic testing requires verifying proper handling of those video formats supported by the
HDMI display. Using the table above as a guide, you can verify your display's support for
one or more EIA/CEA-861-B formats.
To test an HDMI display using supported HDMI formats:
1. Connect an HDMI display to the Tx connector on the generator.
2. If necessary, set up the generator for HDMI output.
• See "Setting up the generator for HDMI
up the generator for HDMI operation.
3. Using the Format knob, specify the HDMI video format you want to test.
Quantum Data format
288p2xS1, 288p2xS2, 288p2xS3
576i4x25, 576i4xLH
576i4xSH
288p4x_1, 288p4x_2, 288p4x_3, 288p4xL1,
288p4xL2, 288p4xL3
288p4xS1, 288p4xS2, 288p4xS3
576p2x50, 576p2xLH
576p2xSH
1080p50
1080p23, 1080p24
1080p25
1080p29, 1080p30
operation" on page 147 for steps on setting
