802BT/802R Video Test Generator User Guide
4. Using the Format knob, select the signal format you want to use.
Any built-in formats may be used for this test. However, we recommend using several
formats spread over a wide range of frequencies. For example, the Test165 format is
commonly used to test at the maximum pixel frequency (165 MHz), while the DMT0660
format can be used to test at a very low frequency (25.175 MHz).Use the following
formats to test single-link DVI over a range of frequencies:
Format
TEST165
DMT1660
DMT1285G
DMT1285A
DMT1648
DMT1275A
DMT1185
DMT1260G
DMT1085
DMT1170
DMT1075
DMT1070
720p60
DMT1060
DMT0885
DMT0872
DMT0875
DMT1043
DMT0860
DMT0685
DMT0785H
DMT0675
SMT0760V
DMT0660
5. Start the analyzer (see
Pixel rate (Mhz)
165.000
162.000
157.500
148.500
135.000
129.600
121.500
108.000
94.500
94.200
78.750
75.000
74.250
65.000
56.250
50.000
49.500
44.900
40.000
36.000
35.500
31.500
28.322
25.175
"Starting the analyzer" on page 113).
