30 Chapter 2 Testing Video Displays
Display type Display test
Digital flat panel Pixel anomalies (stuck pix-
(fixed pixel dis- els, misc sampling)
play)
Photometry (chrominance,
contrast, levels)
Luminance
Centering
Resolution
Persistence
Recommended images
Flat, Raster, Ramp_B, Ramp_G, and
Focus_@6, Focus_@7, Focus_@8,
Focus_@9, Text_9, Text_9T, Text_11,
Text_12T, Text_16
Flat, Flat07, Flat13, Flat20, Flat27, Flat33,
Flat40, Flat47, Flat53, Flat60, Flat67, Flat73,
Flat80, Flat87, Flat93, FlatGray, Flat_01,
Flat_02, Flat_03, Flat_04, Flat_05, Flat_06,
Flat_07, Flat_08, Flat_09, Flat_10, Flat_11,
Flat_12, Flat_13, Flat_14, Flat_15,
Ramp_B, Ramp_G, and Ramp_R, ColorBar,
SMPTEbar, SMPTE133
SMPTE133 (grayscale), Grays5, Grays9,
Grays11, Grays16, Grays32, Grays64
Outline0, Outline1, Outline2, Outline3
BurstTCE, Grill_11, Grill_15, Grill_22, Grill_33,
Grill_44
Animated images: Persist, Cubes, SlideX
Ramp_R,
Flat_16,
