EDID testing for source devices

Testing response of source to EDID

802BT/802R Video Test Generator User Guide
The generator can emulate an HDMI/DVI sink (display) in order to test HDMI source
devices.
The analyzer can emulate different HDMI/DVI displays using a built-in, configurable EDID
structure. With this capability an HDMI/DVI source device can be tested for its ability to
handle an EDID structure received from virtually any DDC-compatible display. You first
have to configure the generator to support the HDMI/DVI signal source and enable
measuring of internal signals. You then configure the EDID in accordance with a particular
display. Use the following procedures.
To set up the generator to perform HDMI/DVI testing:
1. Hold down the G and B keys, and then power on the generator.
The following message appears on the front panel LCD.
Special: keys
Digital friendly
2. Release the G and B keys.
The generator is placed in Digital Friendly mode.
3. Hold down the R and ACS keys, and then cycle the power to the generator.
The following message appears on the front panel LCD.
Special: keys
hot-plug formats
4. Hold down the Step, G, and B keys while starting the genertor, until Status display
appears on the LCD.
167
