ib sm multicast
ib sm multicast
To administer the subnet manager (SM) multicast on your Server Switch, and to create and populate
partitions, enter the ib sm multicast command in Global Configuration mode. To undo configurations
and partitions, use the no form of this command. Enter this command without arguments to add a subnet
manager with default values.
Syntax Description
subnet-prefix
prefix
multicast
mgid
GID-address
mtu
MTU-value
q_key
qkey
rate
GBPS
sl
service-level
ipoib
scope
link-local
site-local
org-local
global
Defaults
There are no defaults for this command.
Command Modes
Global Configuration (config) mode.
Cisco SFS 7000 Series Product Family Command Reference Guide
4-12
ib sm subnet-prefix prefix [multicast {mgid GID-address [mtu MTU-value] [p_key pkey]
|[q_key qkey] [rate GBPS] [sl service-level] | ipoib p_key pkey [mtu MTU-value] [q_key
qkey] [rate GBPS] [scope {link-local | site-local | org-local | global}]
no ib sm subnet-prefix prefix [multicast {mgid GID-address [mtu MTU-value] [p_key pkey]
|[q_key qkey] [rate GBPS] [sl service-level] | ipoib p_key pkey [mtu MTU-value] [q_keyqkey]
[rate GBPS] [scope {link-local | site-local | org-local | global}]
Specifies the subnet prefix of the subnet manager.
Subnet prefix of the subnet manager. You may enter any prefix, but we
recommend that you enter fe:80:00:00:00:00:00:00 to indicate a locally
administered subnet.
Creates a multicast group.
Specifies the global ID of the multicast group.
Global ID of the multicast group.
(Optional) Specifies the maximum transmission unit of the multicast group.
(Optional) Maximum transmission unit of the multicast group.
(Optional) Specifies the queue key of the multicast group.
(Optional) Queue key of the multicast group.
(Optional) Specifies the data rate of the multicast group, in Gbps.
(Optional) Data rate of the multicast group, in Gbps.
(Optional) Specifies the service level of the multicast group.
(Optional) Service level of the multicast group.
(Optional) Creates an IPoIB broadcast multicast group.
(Optional) Specifies the scope of the broadcast multicast group.
(Optional) Applies a link-local scope to the broadcast multicast group.
(Optional) Applies a site-local scope to the broadcast multicast group.
(Optional) Applies a org-local scope to the broadcast multicast group.
(Optional) Applies a global scope to the broadcast multicast group.
Chapter 4
InfiniBand Commands
OL-9163-02
