Chapter 6
Show Commands
Table 6-61
Field
out-octets
out-ucast-pkts
out-multicast-pkts
out-broadcast-pkts
out-discards
out-errors
link-events
fcp-cmds-outstanding
fcp-cmds-completed
fcp-errors
fc-initiator-IO
Table 6-62
Table 6-62
Field
wwpn
wwnn
description
ioc-guid
service-name
OL-9163-02
statistics Keyword Output Field Descriptions (continued)
Description
Cumulative number of octets transmitted out of the interface, including
framing characters.
Cumulative number of packets that higher-level protocols requested be
transmitted and that were not addressed to a multicast or broadcast address
at this sub-layer, including those that were discarded or not sent.
Cumulative number of packets that higher-level protocols requested be
transmitted and that were addressed to a multicast address at this
sub-layer, including those that were discarded or not sent. For a MAC
layer protocol, this includes both Group and Functional addresses.
Cumulative number of packets that higher-level protocols requested to be
transmitted and that were addressed to a broadcast address at this
sub-layer, including those that were discarded or not sent.
Cumulative number of outbound packets that were chosen to be discarded
even though no errors had been detected to prevent their being transmitted.
One possible reason for discarding such a packet could be to free-up buffer
space.
For packet-oriented interfaces, the cumulative number of outbound
packets that could not be transmitted because of errors. For
character-oriented or fixed-length interfaces, the number of outbound
transmission units that could not be transmitted because of errors.
Cumulative number of link events processed by the Fibre Channel
interface port.
Cumulative number of FCP commands outstanding on the Fibre Channel
interface port.
Cumulative number of FCP commands completed on the Fibre Channel
interface port.
Cumulative number of FCP errors encountered on the Fibre Channel
interface port.
Cumulative number of transactions between the Fibre Channel initiator
and this port.
describes the fields in the targets keyword output.
targets Keyword Output Field Descriptions
Description
World-wide port name (WWPN) of the target.
World-wide node name (WWNN) of the target.
Dynamically-assigned or administratively-assigned description of the target. Enter
the fc srp target command with the description keyword to configure this field.
I/O controller (IOC) GUID of the FC gateway that accesses the target.
Name of the service that the target runs.
Cisco SFS 7000 Series Product Family Command Reference Guide
show interface fc
6-159
