Chapter 6
Show Commands
Table 6-8
Field
oper code
boot stage
OL-9163-02
show card Command Field Descriptions (continued)
Description
Displays the general condition of the interface card. The general condition may
appear as any of the following:
•
unknown
•
normal
•
wrongBootImage
bootFailed
•
tooHot
•
checkingBootImage
•
•
rebooting
•
booting
•
standby
recoveryImage
•
A condition of "unknown" indicates an unsupported interface card. To address
this condition, replace the card with a supported card.
The oper code of a card must appear as normal for the oper status of the card
to appear as up.
A wrong-image condition indicates that the active system image on the
interface card does not match the active system image on the controller. All
cards must run the same active system image as the controller card to function.
A bootFailed condition indicates that the active system image on the card was
incompletely or incorrectly loaded. If the other interface cards come up
successfully, reset the individual card. Otherwise, reboot your entire Server
Switch.
When your card overheats, the tooHot condition appears in the show card
command output. Enter the show fan command to see if your fans have failed.
The booting condition indicates that the card has not finished loading the
necessary image data for internal configuration.
Boot Stage could be any of the following:
•
recovery
ipl
•
•
ppcboot
fpga
•
•
pic
ib
•
•
rootfs
kernel
•
•
exe
done
•
Cisco SFS 7000 Series Product Family Command Reference Guide
show card
6-19
