show ib-agent switch
Table 6-53
Table 6-53
Field
node-guid
in-ib-port
out-ib-port
SL to VL mapping
Table 6-54
Table 6-54
Field
guid
lft-cap
rft-cap
mft-cap
lft-top
default-port
def-mcast-pri-port
def-mcast-NP-port
life-time-value
port-state-change
lids-per-port
partition-enf-cap
inbound-enf-cap
outbound-enf-cap
filter-raw-pkt-in-cap
filter-raw-pkt-out-cap
Cisco SFS 7000 Series Product Family Command Reference Guide
6-144
describes the fields in the sl-vl-map keyword output.
sl-vl-map Keyword Output Field Descriptions
Description
GUID of the SMA node.
The ingress port of an InfiniBand data packet.
The egress port of an InfiniBand data packet.
For each service lane, show the underlying virtual lane which will be used for a
packet on the given ingress port, which will be routed out the given egress port.
describes the switch info keyword output fields.
switch info Keyword Output Field Descriptions
Description
GUID of the SMA node.
The current maximum used entry in the Linear Forwarding Table.
The maximum capacity of the switch Random Forwarding Table. (This
capacity is generally unmet, since only one LFT or RFT is implemented on
any given switch and all Cisco SFS 7000 switches use the LFT.)
The maximum capacity of the Multicast Forwarding Table.
The current maximum used entry in the Linear Forwarding Table.
Port used if the Random Forwarding Table is implemented. This port is the
one to which packets are sent when the LID is not specified in the Random
Forwarding Table.
Default Multicast Primary Port—port to which multicast packets are sent
when the LID is not present in the Multicast Forwarding Table.
Default Multicast Not Primary Port—Same as above, but for multicast
packets arriving on the Default Multicast Primary Port.
Specifies the maximum time a packet can live in the switch. See the
InfiniBand specification for the definition of this value.
Indicates that a port on the switch has changed its state. Used by the subnet
manager to determine if it needs to look at the port states.
Specifies the number of LID/LMC combinations that may be used per port if
the Random Forwarding Table is implemented.
The number of entries in the Partition Enforcement Table per port.
Indicates whether or not the switch is capable of partition enforcement on
inbound (received) packets.
Indicates whether or not the switch is capable of partition enforcement on
outbound (transmitted) packets.
Indicates whether or not the switch is capable of raw packet enforcement on
inbound (received) packets.
Indicates whether or not the switch is capable of raw packet enforcement on
outbound (transmitted) packets.
Chapter 6
Show Commands
OL-9163-02
