show interface ib
Table 6-72
Field
resp-timeout
local-phys-err
overrun-err
Command Output:
Table 6-73
interface ib command.
Table 6-73
Field
port
name
in-octets
in-ucast-pkts
in-multicast-pkts
in-broadcast-pkts
in-discards
in-errors
in-unknown-protos
out-octets
out-ucast-pkts
Cisco SFS 7000 Series Product Family Command Reference Guide
6-174
sma port-info details Keyword Output Field Descriptions (continued)
Description
Maximum time allowed between the port reception of a subnet
management packet and the transmission of the associated response. For
more information, see InfiniBand Architecture®, Vol. 1, Release 1.1,
section 13.4.6.2, "Timers and Timeouts."
Threshold at which ICRC, VCRC, FCCRC, and all physical errors result
in an entry into the BAD PACKET or BAD PACKET DISCARD states of
the local packet receiver. For more information, see InfiniBand
Architecture®, Vol. 1, Release 1.1, section 7.12.2, "Error Recovery
Procedures."
Threshold at which buffer count overruns across consecutive flow-control
update periods and results in an overrun error.
describes the fields that appear when you use the statistics keyword with the show
statistics Keyword Output Field Descriptions
Description
Port identifier, in slot#/port# format.
Administrative port name that you configured with the name command.
Cumulative number of octets that arrived at the port, including framing
characters.
Cumulative number of incoming packets destined for a single port.
Cumulative number of incoming packets destined for the ports of a multicast
group.
Cumulative number of incoming packets destined for all ports on the fabric.
Cumulative number of inbound packets that the port discarded for a reason other
than a packet error (for example, lack of buffer space).
Number of inbound packets with errors that the port discarded.
For packet-oriented interfaces, the number of packets that were received through
the interface that were discarded because of an unknown or unsupported
protocol. For character-oriented or fixed-length interfaces that support protocol
multiplexing, the number of transmission units received through the interface
that were discarded because of an unknown or unsupported protocol. For any
interface that does not support protocol multiplexing, this counter is always 0.
Total number of octets transmitted out of the interface, including framing
characters.
Total number of packets that higher-level protocols requested be transmitted and
that were not addressed to a multicast or broadcast address at this sub-layer,
including those that were discarded or not sent.
Chapter 6
Show Commands
OL-9163-02
