xStack DGS-3120 Series Layer 3 Managed Gigabit Switch CLI Reference Guide
Format
show mac_based_vlan {mac_address <macaddr> | [vlan <vlan_name 32> | vlanid <vlanid 1-
4094>]}
Parameters
mac_address - (Optional) Specify the entry that you would like to display.
<macaddr> - Enter the MAC address used here.
vlan - (Optional) Specify the VLAN that you would like to display.
<vlan_name 32> - Enter the VLAN name here. This name can be up to 32 characters long.
vlanid - (Optional) Specify the VLAN by VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID here. This value must be between 1 and 4094.
Restrictions
None.
Example
In the following example, MAC address "00-80-c2-33-c3-45" is assigned to VLAN 300 by manual
config. It is assigned to VLAN 400 by Voice VLAN. Since Voice VLAN has higher priority than
manual configuration, the manual configured entry will become inactive. To display the MAC-
based VLAN entry:
DGS-3120-24TC:admin# show mac_based_vlan
MAC Address
-----------------
00-80-e0-14-a7-57
00-80-c2-33-c3-45
00-80-c2-33-c3-45
Total Entries : 3
DGS-3120-24TC:admin#
VLAN ID Status
------- --------
200 Active
300 Inactive
400 Active
583
Type
-------------------
Static
Static
Voice VLAN
