xStack DGS-3120 Series Layer 3 Managed Gigabit Switch CLI Reference Guide
Restrictions
None.
Example
To show the whole IPv6 multicast routing table generated on the Switch:
DGS-3120-24TC:admin#show pim6 mroute
Command: show pim6 mroute
Total (*,*,RP) Entries
Total (*,G) Entries
Total (S,G) Entries
Total (S,G,rpt) Entries : 1
Group : FF13::100
Source : *
Outgoing : n10 n30
Group : FF13::100
Source : 2001::1111
Outgoing: n10
Group : FF13::102
Source : 2001::3F6D
Outgoing: n20
Group : FF13::100
Source : 2001::1111
RP Address: 3FFE:10:10::153
Outgoing : -
Total Entries: 4
DGS-3120-24TC:admin#
80-13 show pim6 mroute star_g
Description
This command is used to display the multicast routing information for (*, G) entries generated by
PIM6.
Format
show pim6 mroute star_g {group <ipv6addr> {ipif <ipif_name 12>}}
Parameters
group - (Optional) Specify the IPv6 multicast group address to be displayed.
<ipv6addr> - Enter the IPv6 address.
ipif - (Optional) Specify the IPv6 interface to be displayed.
: 0
: 1
: 2
Upstream: n1
Upstream: n2
Upstream: n2
rpt, Upstream: n1
779
