xStack DGS-3120 Series Layer 3 Managed Gigabit Switch CLI Reference Guide
DGS-3120-24TC:admin#config surveillance_vlan priority 6
Command: config surveillance_vlan priority 6
Success.
DGS-3120-24TC:admin#
94-4 config surveillance_vlan oui
Description
This command is used to configure the user-defined surveillance traffic OUI. OUI is used by the
Switch to identify the surveillance traffic packets. Apart from the pre-defined OUIs, the user can
further create user-defined OUI if needed. A user-defined OUI cannot be the same as any of the
pre-defined OUI.
Format
config surveillance_vlan oui [add | delete] <macaddr> <macmask> {component_type [vms |
vms_client | video_encoder | network_storage | other] description <desc 32>}
Parameters
add - Specify to add a user-defined OUI of a surveillance device vendor.
delete - Specify to remove a user-defined OUI of a surveillance device vendor.
<macaddr> - The user-defined OUI MAC address.
<macmask> - The user-defined OUI MAC address mask.
component_type - (Optional) Specify the surveillance components that could be auto-detected
by surveillance VLAN.
vms - Specify the Video Manage Server (VMS) to be auto-detected by surveillance VLAN.
vms_client - Specify the VMS client to be auto-detected by surveillance VLAN.
video_encoder - Specify the video encoder to be auto-detected by surveillance VLAN.
network_storage - Specify the network storage to be auto-detected by surveillance VLAN.
other - Specify other surveillance devices to be auto-detected by surveillance VLAN.
description - Specify the description for the user-defined OUI.
<desc 32> - Enter the description.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To add a user-defined OUI of a surveillance device:
DGS-3120-24TC:admin#config surveillance_vlan oui add AA-BB-CC-DD-EF-FF FF-FF-FF-
00-00-00 component_type other description abc
Command: config surveillance_vlan oui add AA-BB-CC-DD-EF-FF FF-FF-FF-00-00-00
component_type other description abc
Success.
DGS-3120-24TC:admin#
