xStack DGS-3120 Series Layer 3 Managed Gigabit Switch CLI Reference Guide
Chapter 82 QinQ Command List (RI and

enable qinq

disable qinq
config qinq inner_tpid <hex 0x1-0xffff>
config qinq ports [<portlist> | all] {role [uni | nni] | missdrop [enable | disable] | outer_tpid <hex
0x1 - 0xffff> | use_inner_priority [enable | disable] | add_inner_tag [<hex 0x1 - 0xffff> |
disable]}
show qinq
show qinq inner_tpid
show qinq ports {<portlist>}
create vlan_translation ports [<portlist> | all] [add cvid <vidlist> | replace cvid <vlanid 1-4094>]
svid <vlanid 1-4094> {priority <priority 0-7>}
delete vlan_translation ports [<portlist> | all] {cvid <vidlist>}
show vlan_translation {[ports <portlist> | cvid <vidlist>]}
82-1 enable qinq
Description
This command is used to enable QinQ. When QinQ is enabled, all network port roles will be NNI
ports; all existing static VLANs will run as S-VLAN; all dynamic learned L2 address will be cleared;
all dynamic registered VLAN entries will be cleared; and GVRP will be disabled.
To run GVRP on the Switch, the administrator should enable GVRP manually. In QinQ mode,
GVRP protocol will employ reserve address 01-80-C2-00-00-0D.
Format
enable qinq
Parameters
None.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To enable QinQ:
EI Mode Only)
794
