xStack DGS-3120 Series Layer 3 Managed Gigabit Switch CLI Reference Guide
<sec 1-18724> - Enter the hello time value here. This value must be between 1 and 18724
seconds. The default value is 30 seconds.
jp_interval - Specify the interval between transmitting (flooding to all interfaces) multicast
messages to downstream routers, and automatically 'pruning' a branch from the multicast
delivery tree. This interval also determines the time interval the router uses to automatically
remove prune information from a branch of a multicast delivery tree and begin to flood
multicast messages to all branches of that delivery tree. These two actions are equivalent.
The default is 60 seconds.
<sec 1-18724> - Enter the join/prune interval value here. This value must be between 1 and
18724 seconds.
state - Specify to allow the PIM function to be disabled or enabled for the above IP interface.
The default is disabled.
enable - Specify that the PIM function will be enabled.
disable - Specify that the PIM function will be disabled.
mode - Specify the multicast protocol mode used. – dense mode or sparse mode, or sparse-
dense mode. The default value is dense mode.
dm - Specify that the multicast protocol mode will be set to dense mode.
sm - Specify that the multicast protocol mode will be set to sparse mode.
sm-dm - Specify that the multicast protocol mode will be set to sparse-dense mode.
dr_priority - Specify the priority for DR (Designated Router) election. The DR will forward
multicast traffic from a unicast source to the appropriate RP (Rendezvous Point). The router
with the highest priority value will be elected as the DR in the VLAN. When multiple routers
are configured with the same highest priority value, the router with the highest IP addres will
the elected as the DR.
<uint 0-4294967294> - Enter the DR priority value used here. This value must be between 0
and 4294967294.
register_probe_time - Specify the time before the Register-Stop Timer expires. This is used
when a DR may send a Null-Register to the RP to cause it to resend a Register-Stop
message. The default value is 5 sec.
<value 1-127> - Enter the register probe time value here. This value must be between 1 and
127.
register_suppression_time - Specify the period after which a PIM DR will stop sending register
encapsulated data to the RP after receiving a Register-Stop message. The default value is 60
sec.
<value 3-255> - Enter the register suppression time value here. This value must be between 3
and 255.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure PIM configurations of IP interface System:
DGS-3120-24TC:admin#config pim ipif System hello 35 jp_interval 70 state enable
Command: config pim ipif System hello 35 jp_interval 70 state enable
Success.
DGS-3120-24TC:admin#
79-2 enable pim
Description
This command is used to enable PIM on the switch.
752
