Element Permitted Values
lb UTF-8 encoded string
of up to 40 bytes
pt "SIP", "H323", or
"Unspecified"
rt Null, 1 to 21
dc UTF-8 encoded string
containing digits (the
user part of a SIP
URL) or a string that
constitutes a valid SIP
URL
ad 0,1
ar 0,1
bw 0,1
bb 0,1

Local Digit Map

Interpretation
label
Note: In some cases, this will be less than 40 characters due to
UTF-8's variable length encoding.
Note: The label of a contact directory item is by default the label
attribute of the item. If the label attribute does not exist or is Null, then
the concatenation of first name and last name will be used as label. A
space is added between first and last names.
protocol
The protocol to use when placing a call to this contact.
ring type
When incoming calls can be associated with a directory entry by
matching the address fields, this field is used to specify ring type to
be used.
divert contact
The forward-to address for the autodivert feature.
auto divert
If set to 1, automatically diverts callers that match the directory entry
to the address specified in divert contact.
Note: If auto-divert is enabled, it has precedence over auto-reject.
auto-reject
If set to 1, automatically rejects callers that match the directory entry.
Note: If auto-divert is also enabled, it has precedence over
auto-reject.
buddy watching
If set to 1, add this contact to the list of watched phones.
buddy block
If set to 1, block this contact from watching this phone.
The phone has a local digit map feature to automate the setup phase of
number-only calls. When properly configured, this feature eliminates the need
for using the Dial or Send soft key when making outgoing calls. As soon as a
digit pattern matching the digit map is found, the call setup process will
complete automatically. The configuration syntax is based on
recommendations in 2.1.5 of RFC 3435. The phone behavior when the user
dials digits that do not match the digit map is configurable. It is possible to
strip a trailing # from the digits sent or to replace certain matched digits (with
