Polycom IP 320 Administrator's Manual page 47

Name Possible Values
Server Address dotted-decimal IP address
OR
domain name string
OR
URL
All addresses can be followed
by an optional directory and
optional file name.
Server User any string
Server Password any string
File Transmit Tries 1 to 10
Default 3
Retry Wait 0 to 300
Default 1
Tag SN to UA Disabled, Enabled
Note
The Server User and Server Password parameters should be changed from the
default values. Note that for insecure protocols the user chosen should have very
few privileges on the server.
Description
The provisioning server to use if the DHCP client is
disabled, the DHCP server does not send a boot server
option, or the Boot Server parameter is set to Static. The
phone can contact multiple IP addresses per DNS name.
These redundant provisioning servers must all use the
same protocol. If a URL is used it can include a user
name and password. Refer to
Protocols on page 3-4. A directory and the master
configuration file can be specified.
Note: ":", "@", or "/" can be used in the user name or
password these characters if they are correctly escaped
using the method specified in RFC 1738.
The user name used when the phone logs into the server
(if required) for the selected Server Type.
Note: If the Server Address is a URL with a user name,
this will be ignored.
The password used when the phone logs in to the server
if required for the selected Server Type.
Note: If the Server Address is a URL with user name and
password, this will be ignored.
The number of attempts to transfer a file. (An attempt is
defined as trying to download the file from all IP
addresses that map to a particular domain name.)
The minimum amount of time that must elapse before
retrying a file transfer, in seconds. The time is measured
from the start of a transfer attempt which is defined as the
set of upload/download transactions made with the IP
addresses that map to a given provisioning server's DNS
host name. If the set of transactions in an attempt is equal
to or greater than the Retry Wait value, then there will be
no further delay before the next attempt is started.
For more information, refer to
Provisioning Server on page 3-17.
If enabled, the phone's serial number (MAC address) is
included in the User-Agent header of the Microbrowser.
The default value is Disabled.
Setting up Your System
Supported Provisioning
Deploying Phones From the
3 - 11
