Polycom IP 320 Administrator's Manual page 49

Name Possible Values
Storm Filtering Enabled, Disabled
LAN Port Mode 0 = Auto
1 = 10HD
2 = 10FD
3 = 100HD
4 = 100FD
5 = 1000FD
PC Port Mode 0 = Auto
1 = 10HD
2 = 10FD
3 = 100HD
4 = 100FD
5 = 1000FD
-1 = Disabled
Note
The LAN Port Mode applies to all phones supported by SIP 3.0 . The PC Port Mode
parameters are only available on phones with a second Ethernet port.
Only the SoundPoint IP 560 and 670 and Polycom VVX 1500 phones supports the
LAN Port Mode and PC Port Mode setting of 1000FD.The 1000BT LAN Clock and
1000BT PC Clock parameters are only available on SoundPoint IP 560 and 670
phones
Syslog Menu
Syslog is a standard for forwarding log messages in an IP network. The term
"syslog" is often used for both the actual syslog protocol, as well as the
application or library sending syslog messages.
The syslog protocol is a very simplistic protocol: the syslog sender sends a
small textual message (less than 1024 bytes) to the syslog receiver. The receiver
is commonly called "syslogd", "syslog daemon" or "syslog server". Syslog
messages can be sent through UDP, TCP, or TLS. The data is sent in cleartext.
Syslog is supported by a wide variety of devices and receivers. Because of this,
syslog can be used to integrate log data from many different types of systems
into a central repository.
The syslog protocol is defined in RFC 3164. For more information on syslog,
go to http://www.ietf.org/rfc/rfc3164.txt?number=3164
Description
Filter received Ethernet packets so that the TCP/IP stack
does not process bad data or too much data.
Enable/disable the DoS storm prevention state.
The default value is Enabled.
The network speed over the Ethernet.
The default value is Auto.
HD means half duplex and FD means full duplex.
Note: Polycom recommends that you do not change this
setting.
The network speed over the Ethernet.
The default value is Auto.
HD means half duplex and FD means full duplex.
Note: Polycom recommends that you do not change this
setting unless you want to disable the PC port.
Setting up Your System
.
3 - 13
