Responding to Error Messages

Other Messages

Close xxx Cover (xxx name of the cover)
Problem1: The named cover is open.
Solution1: Close the cover named in display on the
operation panel.
Reset Lever
Problem1: Open the release lever.
Solution1: Pull the release lever toward you to close it.
6- 14
Check Head Hght L/M/H → L/M/H
Problem1: The current height of the printhead (displayed at
the left end of the bottom display line) is not the
appropriate height (displayed at the right end of
the bottom display line) for printing on the type of
media loaded for the print job.
Solution1: Confirm the height (H/M/L) named at the right
end of the bottom display line, then perform
procedure below to adjust the height of the print
head.
1. Press the Online button to set the printer
offline.
2. Hold down [ ] or [
move the carriage to the center.
3. Open the upper cover.
4. Set the printhead height adjustment lever to
the correct position for the media.
5. Raise the upper cover stopper to release the
lock then close the upper cover.
] for more than 1 sec. to
