Printing with Rolls
Media Name
Proofing Paper
Newsprint for Proofing
Fine Art Photo
Fine Art Heavyweight Photo FneArt HW Photo
Fine Art Textured
Canvas SemiGlos
Japanese Paper Washi
Colored Coated Paper
CAD Tracing Paper
CAD Translucent Matte Film CAD Matte Film
Special 1~5
Important
Make sure that you have selected the correct setting
for the media type. If you have selected an incorrect
setting for the media type, do the procedure in
"Selecting the Media Type"
As soon as each sheet is printed, remove it from the
output stacker.
Note
If a message appears in the display after loading roll
paper, the operation panel lamp flashes.
Before shipping a printer, the Media Type is set for
Plain Paper. Or, when the release lever is opened and
closed, the media type setting is reset automatically to
Plain Paper.
The media size is detected automatically, therefore no
setting for the size is required.
2- 31
Media Type Setting
Proofing Paper 2
News Proof/1/2/3
FineArt Photo
FineArt Txtr
Canvas Semi-Gl
JPN Paper Washi
Colored Coated
CAD Trace Paper
Special 1~5
(→ P.2-32).
In order to align the leading edge correctly when the
roll media is replaced with a new one, the media is fed
and then cut the correct amount for the type of media.
Also, if a barcode is printed on the media, the portion
where the barcode is will be cut off after the barcode is
read.
11
If a new roll without barcodes is loaded in the
printer while the paper remains function is
enabled, press [ ] or [
length of roll then press the OK button.
If you have set a roll with media remaining barcodes
printed, the amount of media remaining is detected
automatically so you do not have to select it.
Media Length
30.00 m
After a few seconds, Online appears on the display
and the printer is ready to print.
12
If the output assist guides are not extended,
pull it out.
Important
The output assists guides should always be extended
for printing. If they are not extended, this could lead to
poor print quality.
