Canon imagePROGRAF W6400 User Manual page 385

Print Quality Functions
Correcting Image Offset
If vertical lines are bent, or when colors are faded and
uneven, perform Auto Head Adj. to correct the position of
the printhead. The printer reads the results of a printhead
adjustment pattern as it prints and corrects the position of
the printhead automatically.
Online
Online
Offline
Online
MAIN MENU
Adjust Printer
Auto Head Adj.
Advanced Adj.
* Adjusting Gaps Between
Odd/Even Nozzles, Print-
ing Direction, Color Gaps
Yes
Online
Printing
Online
7- 9
Standard Adj.
* Adjusting Print Direction
No
OK OK
Correcting Horizontal Banding in
Images
Perform Adjust Band to adjust the amount of line feed and
correct undesirable horizontal banding in printouts. The
printer reads the results of a line feed adjustment pattern as
it prints and corrects the amount of line feed automatically.
To adjust the amount of feed, select Feed Priority > Band
Joint > then perform Adjust Band.
Online
Online
Offline
Online
MAIN MENU
Adjust Printer
Feed Priority
Band Joint
OK
Adjust Band
Standard Adj.
* Standard Feed Adjustment
Yes
Online
Printing
Online
Advanced Adj.
* High-Precision Feed Adjustment
No
OK OK
