Printing with Cut Sheets
Printing with Cut Sheets

Loading Cut Sheets

To print on the cut sheet, follow the procedure below.
If there is a cut sheet in the printer, remove it.
(→ P.2-33, P.2-39)
On the printer operation panel, select cut sheet as the
paper feed source. (→ P.2-35)
Place the cut sheet on the platen. (→ P.2-36)
On the printer operation panel, select the media type.
(→ P.2-38)
Adjust the amount of media feed. (→ P.4-42)
Start the print job from the computer. (→ P.1-40)
Important
You must make sure that the printer is switched on
before loading a cut sheet. Also, if the loaded sheet
does not match the media type selected on the
operation panel, this could cause a media loading
error or lead to poor print quality.
Note
Store unused cut sheets in the original package. Store
the package in a cool, dry location that is not exposed
to direct sunlight.
2- 35
Selecting the Paper Source
When printing on the cut sheet, with the operation panel
select cut sheet as the media source.
1
Press and hold the Paper Source button for
1 second or more to light the Cut Sheet
lamp.
Pressing Paper Source alternates the selection
between Roll Media and Cut Sheet.
Information Power
Data
Offline
Feed Papre
Message
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
Offline
Menu
When a roll is loaded, the printer will display
Remove RllMedia?
When another cut sheet is loaded, hold down the
Stop button for more than 1 sec., to display Remove
CutSheet?.
2
If either a cut sheet or roll media is loaded in
the printer, press the OK button.
Remove RllMedia?
Press OK/Stop
Remove either the cut sheet or the roll media.
(→ P.2-33, P.2-39)
