Canon imagePROGRAF W6400 User Manual page 287

TCP/IP Network Settings (Windows, Macintosh, UNIX)
2
Use a LAN cable to connect the computer
LAN port to the HUB port.
Note
When this printer is connected to and used on a
network, switch the printer on then check the LINK
lamp (a) to confirm that it lights and remains on. This
lamp lights green with a 100-Base-TX connection and
lights yellow for a 10-BaseT connection.
If the LINK lamp does not light, check the following
points:
• Is the HUB switched on?
If the HUB is switched off, switch it on.
• Is the LAN cable connected correctly?
Confirm that the LAN cable connectors are clicked
and locked in place correctly.
• Is the LAN cable defective?
Connect another LAN cable and visually check the
lamp again.
• Is the communication method correct for the HUB?
If the communication method (mode and speed) set
for the printer and the HUB with auto recognition do
not match, follow the procedure below to perform the
connection settings manually.
1. Press the Online button to display MAIN MENU.
2. Press [ ] or [
press [ ].
3. Press [ ] or [
press [ ].
4. Press [ ] or [
press [ ].
5- 6
] to select Interface Setup then
] to select Ethernet Driver then
] to select Auto Detect then
5. Press [ ] or [ ] to select Off, then press OK
button.
6. Press [ ] or [ ] to select Comm. Mode then
press [ ].
7. Press [ ] or [ ] to select Half Duplex or Full
Duplex then press OK button.
8. Press [ ] or [ ] to select Ethernet Type then
press [ ].
9. Press [ ] or [ ] to select 10 Base-T or 100
Base-TX then press OK button.
10.Press [ ] or [ ] to select Spanning Tree then
press [ ].
11.Press [ ] or [ ] to select Not Use or Use then
press OK button.
12.Press [ ] twice to display Store Setting then
press [ ].
13.Press the OK button.
