Canon imagePROGRAF W6400 User Manual page 83

Media You Can Use
Cut Sheets
ARCH D to 8 x 10 Standard Sizes, and
Printable
203.2 x 203.2 mm to 609.6 x 1400 mm
Media Size
Custom Sizes
Printable Type All media types
Printing possible inside the area 5 mm in from the top, left and
right area margins, and 23 mm in from the bottom margin.
5 mm
Printable Area
5 mm
23 mm
Data created the same size as cut sheet.
Cut Sheet
Media to Load
Size to
Load
Data created the same size as Media Size.
Print Data and
Results
Original data the
same as the media
2- 21
Important
The print quality or the precision of line feed may
deteriorate at the top margin of the media, or the
surface of the print may appear scratchy. Also, ink may
stick to the top and bottom edges. If the printhead is
scratching the surface of the media, raise the
printhead to a higher position. (→ P.2-40)
When loading cut sheets that are longer than 914 mm
(36"), the trailing edge of the sheet will touch the floor
Media Size
and may become dirty. Before such a long cut sheet,
before you start the print job remove the roll holder and
5 mm
spread a cloth or some paper on the floor, or when the
cut sheet starts to feed tuck the trailing edge into the
output stacker. (→ P.2-39)
Print Area
Media Size
Print Results
TOP
