Function Menus

Menu Settings Summary Tables

Each menu has the functions described below. A setting value marked with an asterisk (*) is the initial setting for that menu
item.

MAIN MENU

Menu Item
Head Cleaning
Force Cutting
Chng Head Hght
Media Type
1- 19
Setting Values
Head Cleaning A
Head Cleaning B
No, Yes
No, Yes
Plain Paper*, CAD Plain Paper, Plain
Paper HQ, Recycled Coated, Coated
Paper, HW Coated, Premium Matte,
Ex HW Coated, Glossy Photo, Semi-
Gl Photo, HW Glossy Photo, HW
SemiGl Photo, Syn. Paper, Adh. Syn.
Paper, Backlit Film, Flame-Res.
Cloth, Proofing Paper, News Proof 1,
News Proof 2, News Proof 3, FineArt
Photo, FneArt HW Photo, FineArt
Txtr, Canvas Semi-Gl, JPN Paper
Washi, Colored Coated, CAD Trace
Paper, CAD Matte Film, Special 1-5
Function
Cleans the printhead.
Performs stronger cleaning than Head
Cleaning A.
Executes a roll cut at the current position.
However, if the media is cut within 10 cm
from the leading edge the media still feeds
the prescribed distance before the cut is
performed. This menu item is displayed only
while Roll Media is selected for printing.
If the feed distance is very small, the cut is
not performed.
Adjusts the height of the Printhead. (→
40)
Selects the type setting for media. Only the
names of the types of media that can be
used with the set Bk ink are displayed.
(→ P.2-4)
