Aligning the Printhead
5
Press [ ] or [
Standard Adj., then press [
Advanced Adj. adjusts the gaps between the even
and odd numbered nozzles, the color boundaries,
and print direction boundaries.
Standard Adj. adjusts only the print direction
boundaries.
Auto Head Adj.
Advanced Adj.
6
Press [ ] or [
OK button.
Advanced Adj.
Yes
As the printhead adjustment pattern prints, the
printer reads the pattern and automatically adjusts
the settings for position of the printhead.
After the printhead adjustment is finished, Online
appears in the printer operation display.
4- 41
] to select Advanced Adj. or
].
↓
] to select Yes, then press
