Handling Jams
Important
Do not pull strongly on the roll media when you align it
with the guideline. The roll media may not feed out
straight in some cases.
If you pull too much of the roll media out, more of the
leading sheet than is needed will be cut.
7
Move the carriage manually when it is out of
its normally parked position.
Push the carriage to the right until it stops.
Important
Be sure to push the carriage to the right. If you push it
to the left, the printer will display a carriage error after
the printer is switched on.
6- 37
8
Raise the upper cover stopper to release the
lock then close the upper cover.
9
If the printer is off, press the Power button to
switch the printer on.
Information Power
Data
Message
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
Offline
Menu
The media starts to feed, and the printer is ready to
use after feeding is finished.
Note
If you need to correct the alignment of the leading
edge, press the Online button to display Offline, press
the [ ] button to feed the media, then select Force
Cutting on MAIN MENU to cut the leading edge.
→
( P.7-3)
After switching roll media and specifying a new media
type, please set the media type on the printer
operation panel. (→ P.2-32)
