Adjusting Amount of Media Feed
4
Press [ ] or [
then press [
Adjust Printer
Adjust Band
5
Press [ ] or [
then press [
Adjust Band
Standard Adj.
6
Press [ ] or [
OK button.
Auto Adjustment
Yes
As the band adjustment pattern prints, the printer
reads the results of the print and automatically
adjusts the settings of the amount of line feed for the
media currently loaded in the printer.
After the amount of line feed has been adjusted, the
printer returns to the Online mode.
4- 43
] to select Adjust Band,
].
↓
] to select Standard Adj.,
].
↓
] to select Yes, then press

Adjusting Line Feed Manually

The line feed can be fine adjusted manually to increase or
decrease the amount of feed. Follow the procedure below
to perform this adjustment manually.
1
Press the Online button to display MAIN
MENU.
MAIN MENU
Head Cleaning
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
2
Press [ ] or [ ] to select Adjust Printer,
then press [ ].
MAIN MENU
↓
Adjust Printer
3
Press [ ] or [ ] to select Adjust Band,
then press [ ].
Adjust Printer
Adjust Band ↓
4
Press [ ] or [ ] to select Fine Tuning,
then press [ ].
Adjust Band
↓
Fine Tuning
Displays the values of the current settings.
