Replacing the Maintenance Cartridge

Replacing the Maintenance Cartridge
The maintenance cartridge vacuums excess ink that
accumulates as a result of borderless printing, printhead
cleaning, and ink mist produced by other operations. When
you see the message prompt that tells you to replace the
maintenance cartridge, replace the cartridge.
Maintenance Cartridge MC-01
4- 16
Checking Spacing Remaining in the
Maintenance Cartridge
You can confirm the amount of space remaining in the
maintenance cartridge at any time by checking the printer
operation panel display. You should always check the
amount of space remaining in the maintenance cartridge
before Heading Cleaning B, moving the printer, or any other
operation that could use up space in the maintenance
cartridge, and then replace the cartridge in advance.
Information Button Display
Ink
You can check on how much space remains in the mainte-
nance cartridge at any time (during a print job or error dis-
play) by pressing the Information button. The icon at the
right end of the bottom line shows you the amount of space
that remains in the maintenance cartridge.
Reading the Maintenance Cartridge Display
The height of the bar tells you how much more ink the
maintenance cartridge vacuum and store.
~700ml ~600ml ~500ml ~400ml
(7dot) (6dot) (5dot)
Information Power
Cleaning
~300ml ~200ml 200ml~0ml
(4dot) (3dot) (2dot) (1dot)
