Color Matching - Canon imagePROGRAF W6400 User Manual

Printing from Windows
Note
Color Adjustment presents the following items for
selection.
Color Adjustment
Cyan
You can calibrate the hues for Cyan,
Magenta
Magenta, Yellow.
Yellow
Adjusts the relative contrast from
Contrast
brightest to darkest colors.
Adjusts the relative contrast from
Vivid
brightest to darkest colors.
Adjusts brightness from the darkest to
Brightness brightest colors so none are lost in the
brightness of the printed image.
Adjusts grayscale from cool colors
Gray Tone
(blue tones) to warm colors (red
Adjustment
tones).
Important
As you change each item, the image of the Preview
on the left changes to reflect the adjustment. The
Original shows the appearance of the initial settings,
and the Preview reflects the current settings.
Even after performing the settings on the Color
Adjustment sheet if you remove the selections of the
Manual Color Settings the Color Adjustment
settings are disabled. Remove the Color Adjustment
selection if you do not want to perform color
adjustments.
3- 46
9

Color Matching

When you print an image captured with a scanner or a
Content
digital camera, sometimes the appearance of the printout
does not match what you see on the screen.
This is caused by differences between the display color
and the printed color. In the Color Settings dialog box
you can use the items on the Matching sheet, that is,
select a color profile ICC (International Color Consor-
tium), or ICM (Image Color Management), or select a
matching mode, input profile, or printer profile, to have
the hues of the colors on the screen more closely resem-
ble the colors in the printout.
1
Click the OK button to close the Color
Settings dialog box.
Open the printer driver dialog box from the
Print dialog box of the application.
Note
For more details about how to open the printer driver
dialog box, please refer to "Printing"
"Basic Procedures". (→ P.1-40)
