Replacing the Cutter Blade

Replacing the Cutter Blade
Follow the procedure below to change the position of a
blade that no longer cuts cleanly. The cutting position can
be changed twice for one blade. Once the cutting position
adjustment dial is set to 3, replace the blade with a new
one.

Cutter Blade CT-02

1
If the printer power is off, press the Power
button to switch the printer on.
Data
Message
Within a short time, Online or Offline is displayed.
2
Press the Online button to display MAIN
MENU.
MAIN MENU
Head Cleaning
4- 29
Information Power
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
Offline
Menu
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
3
Press [ ] or [ ] to display System Setup
then press [ ].
MAIN MENU
System Setup ↓
4
Press [ ] or [ ] to select Change Cutter,
then press [ ].
System Setup
↓
Change Cutter
5
Press [ ] or [ ] to select Yes, then press
OK button.
Change Cutter
Yes
Carriage Moving appears in the bottom line of the
display, and Open Upper Cover appears after the
carriage moves to the center of the platen.
