10 Interrupts

10-2-2 Flow of Operation

1
2
Create
ladder
program
Precautions for Correct Use Precautions for Correct Use
A built-in input cannot be used as a normal input, high-speed counter input, or quick-response
input if it is being used as an interrupt input. Refer to 8-3-3 Allocating Built-in Input Terminals for
details.
PLC Setup
Click the Built-in Input Tab and select Interrupt in the interrupt intput settings.
Select Interrupt
10-4
• Set IN2 to IN7 for interrupt inputs on the Built-in Input
PLC Setup
• Terminals 02 to 07 on the CIO 0 terminal block can be
Write the program in the interrupt task. Interrupt tasks 2 to
7 correspond to interrupt inputs 2 to 7.
Interrupt task
• Specify whether the interrupt is executed when the input
Execute MSKS
instruction in a
• Enable input interrupts in the MSKS instruction. Set N to
cyclic task
Tab Page of the PLC Setup using the CX-Programmer.
used for interrupt inputs. Bits CIO 0.02 to CIO 0.07 cor-
respond to terminals 02 to 07.
turns ON or when it turns OFF in the MSKS instruction.
Set N to 112 to 117 in the MSKS instruction.
102 to 107 in the MSKS instruction.
