Address
Name
Words Bits
A320 00 High-speed Counter 2
Range 1 Comparison
Condition Met Flag
01 High-speed Counter 2
Range 2 Comparison
Condition Met Flag
02 High-speed Counter 2
Range 3 Comparison
Condition Met Flag
03 High-speed Counter 2
Range 4 Comparison
Condition Met Flag
04 High-speed Counter 2
Range 5 Comparison
Condition Met Flag
05 High-speed Counter 2
Range 6 Comparison
Condition Met Flag
08 High-speed Counter 2
Comparison
In-progress Flag
09 High-speed Counter 2
Overflow/Underflow
Flag
10 High-speed Counter 2
Count Direction
A321 00 High-speed Counter 3
Range 1 Comparison
Condition Met Flag
01 High-speed Counter 3
Range 2 Comparison
Condition Met Flag
02 High-speed Counter 3
Range 3 Comparison
Condition Met Flag
03 High-speed Counter 3
Range 4 Comparison
Condition Met Flag
04 High-speed Counter 3
Range 5 Comparison
Condition Met Flag
05 High-speed Counter 3
Range 6 Comparison
Condition Met Flag
CP1E CPU Unit Software User's Manual(W480)
Function
These flags indicate whether the PV is
within the specified ranges when
high-speed counter 2 is being operated
in range-comparison mode for upper
and lower limits.
• Cleared when operation starts.
• Cleared when range comparison
table is registered.
OFF: PV not in range
ON: PV in range
This flag indicates whether a compari-
son operation is being executed for
high-speed counter 2.
• Cleared when operation starts.
OFF: Stopped.
ON: Being executed.
This flag indicates when an overflow or
underflow has occurred in the
high-speed counter 2 PV. (Used with
the linear mode counting range only.)
• Cleared when operation starts.
• Cleared when PV is changed.
OFF: Normal
ON: Overflow or underflow
This flag indicates whether the
high-speed counter 2 is currently being
incremented or decremented. The
counter PV for the current cycle is com-
pared with the PV in last cycle to deter-
mine the direction.
OFF: Decrementing
ON: Incrementing
These flags indicate whether the PV is
within the specified ranges when
high-speed counter 3 is being operated
in range-comparison mode for upper
and lower limits.
• Cleared when operation starts.
• Cleared when range comparison
table is registered.
OFF: PV not in range
ON: PV in range
Status
after Status at
Settings
mode startup
change
Cleared
Cleared
Cleared
Cleared
Cleared
Appendices
Related
Write
flags,
timing
settings
• Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read the
results of
range com-
parison.
Refreshed
when compari-
son operation
starts or stops.
Refreshed
when an over-
flow or under-
flow occurs.
Setting used
for high-speed
counter, valid
during counter
operation.
• Refreshed
each cycle
during over-
seeing pro-
cess.
• Refreshed
when PRV
instruction is
executed to
read the
results of
range com-
parison.
A-61
