5-2

I/O Bits

Overview
These words are allocated to built-in I/O terminals of CP1E CPU Units, built-in analog I/O terminals of
CP1E NA-type CPU Units and CP-series Expansion Units and Expansion I/O Units.
Notation
0 . 02
Bit number: 02
Word number: 0
I/O memory area designator:
None on CX-Programmer,
"CIO" in documentation
Range
Input bits: CIO 0.00 to CIO 99.15 (100 words)
Output bits: CIO 100.00 to CIO 199.15 (100 words)
Applications
Built-in inputs can be used as basic inputs, interrupt inputs, quick-response inputs or high-speed
counters.
Built-in outputs can only be used as basic outputs.
Refer to Section 8 Overview of Built-in Functions and Allocations for details.
Details
• Bits in the CIO Area can be force-set and force-reset.
• The contents of the CIO Area will be cleared in the following cases:
• When the operating mode is changed between PROGRAM or MONITOR mode and RUN mode
• When the PLC power is reset
• When the CIO Area is cleared from the CX-Programmer
• When PLC operation is stopped due to a fatal error other than an FALS error occurs. (The con-
tents of the CIO Area will be retained when FALS is executed.)
Additional Information
Words that are not allocated to the built-in I/O terminals of the CPU Units, built-in analog I/O ter-
minals of CP1E NA-type CPU Units and the Expansion Units and Expansion I/O Units can only
be used in programming. It is the same as the Work Area.
