15 Analog I/O Function
0 to 5 V Outputs
When the resolution is set to 1/6,000, the hexadecimal values 0000 to 1770 (0 to 6,000) correspond
to an analog voltage range of 0 to 5 V.
Specify a negative voltage as a two's complement.
8000
1 to 5 V Outputs
When the resolution is set to 1/6,000, the hexadecimal values 0000 to 1770 (0 to 6,000) correspond
to an analog voltage range of 1 to 5 V.
8000
0 to 20 mA Outputs
When the resolution is set to 1/6,000, the hexadecimal values 0000 to 1770 (0 to 6,000) correspond
to an analog current range of 0 to 20 mA.
8000
4 to 20 mA Outputs
When the resolution is set to 1/6,000, the hexadecimal values 0000 to 1770 (0 to 6,000) correspond
to an analog current range of 4 to 20 mA.
8000
15-10
5.25 V
5 V
FED4
( 300) 0000 (0)
0 V 1770
(6000)
0.25 V
5.2 V
5 V
1 V
0.8 V
FED4
0 V 1770
( 300)
(6000)
21 mA
20 mA
0000 (0)
1770
0 mA
(6000)
20.8 mA
20 mA
4 mA
3.2 mA
1770
FED4 0 mA
(6000)
( 300)
Conversion Data
189C
7FFF
Hexadecimal (Decimal)
(6300)
Conversion Data
189C 7FFF
Hexadecimal (Decimal)
(6300)
Conversion Data
189C
7FFF
Hexadecimal (Decimal)
(6300)
Conversion Data
189C
7FFF
Hexadecimal (Decimal)
(6300)
