18-2 Overview of CX-Programmer

This section describes the preparations that must be completed before a ladder program can be cre-
ated, including connecting the CP1E to the computer and installing the USB driver.

18-2-1 CX-Programmer

The CX-Programmer is a programming application for creating the ladder programs that are executed in
a CP1E CPU Unit.
In addition to ladder program creation, the CX-Programmer also has functions that are needed to set up
and operate the CP1E, including functions for debugging ladder programs, displaying addresses and
present values, monitoring, setting the connected PLC, programming, and monitoring.
The CX-Programmer has fewer sub-menus, making it relatively simple.
The installation of the CX-Programmer is described in 4-1-5 Installing the Software in the CP1E CPU
Unit Hardware User's Manual (Cat. No. W479).
For details on the operation of the CX-Programmer, refer to the CX-Programmer Online Help.

18-2-2 CX-Programmer Flow from Startup to Operation

The flow of using the CX-Programmer from startup through starting PLC operation is shown below.
1
Start CX-Programmer
2
Create new project
3
Create program
4
Save program
5
Connect online to the CP1E
6
Change operating mode
7
Transfer program/PLC system
settings
8
Restart the CP1E
9
Start operation
CP1E CPU Unit Software User's Manual(W480)
18 Programming Device Operations
Select Start - Programs - OMRON - CX-One - CX-Programmer -

CX-Programmer .

Select CP1E in the Change PLC Dialog Box.
Example: Press the C Key to input a NC input condition.
Select File - Save As.
Select PLC - Work Online.
Select PLC - Operating mode - Program.
Select PLC - Transfer - Transfer [PC
Once turn OFF the power supply to the CP1E CPU Unit, then turn
ON again.
CP1E CPU Unit operation will start.
PLC].
