17 Ethernet Option Board
4
Connect the target PLC online
Select Work Online in the PLC menu.
17-38
• The default setting for Address Conversion Mode of the Ethernet Option Board is
Auto (Dynamic), so slecet Auto-detect in the field of Workstation Node Number.
Therefore, according to computer's IP address, computer's FINS node address is set
automatically in the CX-Programmer. At that time, IP address post number and FINS
node address are the same.
In this example, 2 is displayed according to the host number of computer's IP
address 192.168.250.2 set by manual, and it is invalid to change the setting.
• Set IP address to 192.168.250.1, which is the Ethernet Option Board's IP address.
• Set FINS/UDP Port to 9600 (default), which is the UDP port number in the FINS
communications service.
CP1E CPU Unit Software User's Manual(W480)
