17 Ethernet Option Board
FINS Node Address of the Ethernet Option Board
The FINS node address of the Ethernet Option Board is factory-set to 1.
Local FINS Node Address=1
It can be changed in the Settings from the Web browser. The setting range is 1 to 254.
IP Address of the Ethernet Option Board
The IP address of the Ethernet Option Board (Local IP address) is factory-set to 192.168.250.1.
Local IP Address=192.168.250.1
Local IP address can be set by the following two methods.
Method 1: Set in the Settings from the Web browser
Method 2: Set to 0.0.0.0 from the Web browser, and then set in the allocated words in the DM area
(D1355 and D1356) by the ladder programmer
If the local IP address is set neither by method 1 nor by method 2 (at default settings), it remains
192.168.250.1.
IP ADDRESS:
SUBNET MASK:
COMM ERR 10BASE-T
100BASE-TX
Confirmation on Local IP Address
The local IP address can be confirmed in the allocated words in the DM area (D1355 and D1356),
when the power of the PLC is turned OFF and then ON again.
17-14
IP address
Factory setting
192.168.250.1
Except 192.168.250.1
When setting neither in the
allocated words in the DM area
Method 1: Set by the Web browser
nor by the Web browser function
function
Remains the default setting
192.168.250.1
It is the IP address set in the
Settings from the Web browser
Method 2: Set to 0.0.0.0 from the Web
browser, and then set in the allocated
words in the DM area
It is the IP address set in the allocated
words in the DM area (D1355, D1356)
