CP1E CPU Unit Manuals

Information on the CP1E CPU Units is provided in the following manuals.
Refer to the appropriate manual for the information that is required.
Mounting and
1
Setting Hardware
· Names and specifications of the parts of all Units
· Basic system configuration for each CPU Unit
· Connection methods for Expansion I/O Units
and Expansion Units
2
Wiring
· Wiring methods for the power supply
· Wiring methods between external I/O devices
and Expansion I/O Units or Expansion Units
Connecting
3
Online to the PLC
Connecting Cables for CX-Programmer
Support Software
4
Software Setup
5
Creating the Program
Checking and
6
Debugging Operation
Maintenance and
7
Troubleshooting
Error codes and remedies if a problem occurs
2
CP1E CPU Unit Hardware
User's Manual(Cat. No. W479)
This Manual
CP1E CPU Unit Software
User's Manual(Cat. No. W480)
Procedures for connecting the
CX-Programmer Support Software
Software setting methods for the CPU
Units (PLC Setup)
· Program types and basic information
· CPU Unit operation
· Internal memory
· Built-in CPU functions
· Settings
· Checking I/O wiring, setting the Auxiliary Area
settings, and performing trial operation
· Monitoring and debugging with the
CX-Programmer
CP1E CPU Unit Software User's Manual(W480)
CP1E CPU Unit Instructions
Reference Manual(Cat. No. W483)
Detailed information on
programming instructions
