8 Overview of Built-in Functions and Allocations
Prohibiting Repeated Use of Input Terminal Number
The input terminals 00 to 11 of CIO 0 are used for input interrupts, quick-response inputs, high-speed
counters, origin searches and normal inputs. Therefore, do not use the input terminals repeatedly. For
example, if quick-response input 2 is used, then input terminal 02 is occupied, so it cannot be used for
normal input 2, input interrupt 2, quick-response input 2, counter 2 (increment), counter 1 (phase-
A/increment) or counter 0 (direction).
8-3-4

Allocating Built-in Output Temrinals

Allocating Functions to Built-in Output Terminals

Output terminals are allocated functions by setting parameters in the PLC Setup. Set the PLC Setup so
that each terminal is used for only one function.
E14/20/30/40, N14/20/30/40/60 or NA20 CPU Units
Output terminal block
Terminal Terminal
block label number
CIO 100 00
01
02
03
04
05
06
07
00 to 03
CIO 101
04 to 07
CIO 102 00 to 07
E10 CPU Units
Output terminal block
Terminal Terminal
block label number
00
CIO 100
01
02
03
Prohibiting Repeated Use of Output Terminal Number
The output terminals 00 to 07 of CIO 100 are used for pulse outputs, PWM outputs and normal outputs.
Therefore, do not use the output terminals repeatedly. For example, if pulse output 0 (direction) is used,
then output terminal 02 is occupied, so it cannot be used for normal output 2.
8-8
When a pulse output instruc-
Other than those
tion (SPED, ACC, PLS2, or
shown at the right
ORG) is executed
Normal outputs
Pulse + Direction Mode
Normal output 0 Pulse output 0, pulse
Normal output 1 Pulse output 1, pulse
Normal output 2 Pulse output 0, direction
Normal output 3 Pulse output 1, direction
Normal output 4
Normal output 5
Normal output 6
Normal output 7
Normal output 8 to 11
Normal output 12 to 15
Normal output 16 to 23
Other than those
shown at the right
Normal outputs
Normal output 0
Normal output 1
Normal output 2
Normal output 3
PLC Setup
Origin search settings on
Pulse Output 0/1 Tab Page
Fixed duty ratio pulse output
Use
−
−
−
−
−
Pulse 0, Error counter reset
output
−
Pulse 1, Error counter reset
output
− −
− −
− −
− −
− −
CP1E CPU Unit Software User's Manual(W480)
When the PWM
instruction is exe-
cuted
Variable-duty-fac-
tor output
PWM output
−
PWM output 0
−
−
−
−
−
−
−
−
−
