Appendices
Address
Name
Words Bits
−
A518 Operation End Time
to
A520
(CP1E
N/NA-
type
CPU
Unit
only)
A525 01 Ethernet Option
Board Reset Flag
(Serial Option Port)
09 Ethernet Option
Board Restart Flag
(Serial Option Port)
A526 00 Built-in RS-232C Port
Restart Bit (CP1E
N/NA-type CPU Unit
only)
01 Serial Option Port
Restart Bit (CP1E
N30/40/60 or NA20
CPU Unit only)
A-72
Function
The time that operation stopped as a
result of changing the operating mode
to PROGRAM mode is stored here in
BCD.
A518.00 to A518.07: Seconds (00 to
59)
A518.08 to A518.15: Minutes (00 to
59)
A519.00 to A519.07: Hour (00 to 23)
A519.08 to A519.15: Day of month (01
to 31)
A520.00 to A520.07: Month (01 to 12)
A520.08 to A520.15: Year (00 to 99)
Note 1 If an error occurs in operation,
the time of the error will be
stored. If the operating mode
is then changed to
PROGRAM mode, the time
that PROGRAM mode was
entered will be stored.
2 The data will be unstable if the
capacitor becomes
discharged.
3 In an E-type CPU Unit, or if
the clock data is not set for an
N/NA-type CPU Unit, the data
will be for 1:01.01 on Sunday
January 1, 2001.
Turn ON this bit to reset the Ethernet
Option Board mounted on the serial
Option port.
Turn ON this bit to restart Ethernet
Option Board mounted on the serial
Option port.
Turn ON this bit to restart the built-in
RS-232C port.
Note This bit is turned OFF automati-
cally when the restart processing
is completed.
Turn ON this bit to restart the Serial
Option port.
Note This bit is turned OFF automati-
cally when the restart processing
is completed.
Status
after Status at
Settings
mode
change
See at left. Retained Retained
OFF to ON: Reset Retained Cleared
OFF to ON: Restart Retained Cleared
OFF to ON: Restart Retained Cleared
OFF to ON: Restart Retained Cleared
port
CP1E CPU Unit Software User's Manual(W480)
Related
Write
flags,
startup timing
settings
See at left.
