Appendices
Address
Name
Words Bits
A300 Error Log Pointer
A310 Manufacturing Lot
Number, Lower Digits
A311 Manufacturing Lot
Number, Upper Digits
A315 13 Option Board Error
Flag
14 Built-in Analog I/O
Error Flag
15 Backup Memory Error
Flag
A316 to High-speed Counter 2
A317 PV
A318 to High-speed Counter 3
A319 PV
A-60
Function
When an error occurs, the Error Log
Pointer is incremented by 1 to indicate
the location where the next error record
will be recorded as an offset from the
beginning of the Error Log Area (A100
to A199).
Note 1 The data will be unstable if the
capacitor becomes
discharged.
2 The Error Log Pointer can be
cleared to 00 by turning
A500.14 (the Error Log Reset
Bit) ON.
3 When the Error Log Pointer
has reached 14 hex (20 deci-
mal), the next record is stored
in A195 to A199 when the next
error occurs.
The manufacturing lot number is stored
in 6 digits hexadecimal. X, Y, and Z in
the lot number are converted to 10, 11,
and 12, respectively.
Examples:
Lot number 01805
A310 = 0801, A311 = 0005
Lot number 30Y05
A310 =1130, A311 = 0005
ON when the Option Board is removed
while the power is being supplied. CPU
Unit operation will continue and the
ERR/ALM indicator will flash.
Note OFF when the error has been
cleared.
ON when a built-in analog I/O error
occurs and stops the operation of
built-in analog I/O. CPU Unit operation
will continue and the ERR/ALM indica-
tor will flash. OFF when the error has
been cleared.
ON when writing to the built-in
EEPROM backup memory fails. CPU
Unit operation will continue and the
ERR/ALM indicator will flash.
Note OFF when the error has been
cleared.
Contains the PV of high-speed counter
2.
• The PV is cleared when operation
starts.
A317 contains the upper 4 digits and
A316 contains the lower 4 digits.
Contains the PV of high-speed counter
3.
• The PV is cleared when operation
starts.
A319 contains the upper 4 digits and
A318 contains the lower 4 digits.
Status
after
Settings
mode
change
00 to 14 hex Retained Retained
Retained Retained
Cleared Cleared
Cleared Cleared
Cleared Cleared
Cleared
Cleared
CP1E CPU Unit Software User's Manual(W480)
Related
Status at Write
flags,
startup timing
settings
Refreshed A500.14
when error
occurs.
Refreshed A402.00,
when a A424
non-fatal error
occurs.
Refreshed A402.00
when a
non-fatal error
occurs.
Refreshed A402.00
when a
non-fatal error
occurs.
• Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
• Refreshed
each cycle
during the
overseeing
processes.
• Refreshed
when PRV
instruction is
executed to
read PV.
