17 Ethernet Option Board
FINS/TCP Connection Setup
Offset 15
D1438
D1439 FINS/TCP connection No.1
D1440 FINS/TCP connection No.1
D1441 FINS/TCP connection No.1
D1442 FINS/TCP connection No.2
D1443 FINS/TCP connection No.2
D1444
D1448
FINS/ TCP Port Settings
15 14 13 12 11 10
D1438 0 0
Bit
0 Reserved
1 Protect setting
2 to 4 Reserved
5 Protect setting
6 to 15 Reserved
FINS/TCP Connection No.1 to 2
Each FINS/TCP connection number has 5 bytes. The configuration of the 5 bytes of data in each
number is as shown in the following diagram.
Destination IP address
17-28
8 7
FINS/TCP Port Settings
FINS/TCP connection No.1
FINS/TCP connection No.1
FINS/TCP connection No.2
FINS/TCP connection No.2
FINS/TCP connection No.2
Reserved (Always 0)
9 8
0 0 0 0 0 0
Protect setting
(Connection No.2)
Settings
Always 0.
0: The IP address of FINS/TCP connection No.1 is not
under the protection.
1: The IP address of FINS/TCP connection No.1 is
under the protection.
Always 0.
0: The IP address of FINS/TCP connection No.2 is not
under the protection.
1: The IP address of FINS/TCP connection No.2 is
under the protection.
Always 0.
Auto-allocated
FINS node
0
7 6 5 4 3 2 1
0 0 0 0 0
Protect setting
(Connection No.1)
Unit operation
